Engine

• Number Of Cylinders

  3 cylinders, in line

• Valve mechanism

  DOHC four-valve roller rocker IN: VVT-iE EX: VVT-i

• Fuel system

  Intake port (multi-point)

• Displacement (cc)

  1490 ccm

• Bore x Stroke (mm x mm)

  80.5 x 97.6 mm

• Compression Ratio

  14.0:1

• Maximum power output (kW/rpm)

  85 kW@rpm

• Maximum torque (Nm/rpm)

  120/3600-4800 Nm@rpm

• Battery Capacity (Ah)

  4.3 Ah

• Electric Front Motor: Type

  Permanent magnet synchronous motor

• Electric Front Motor: Maximum Output (kW)

  59 kw

• Electric Front Motor: Maximum Torque (Nm)

  141 Nm

Transmission

• Transmission Type

  CVT

Performance

• Maximum Speed (km/h)

  170 km/h

• 0-100 km/h (secs)

  11.2 seconds

• Drag Coefficient

  0.35

Suspension

• Front

  MacPherson strut

• Rear

  Torsion beam

Brakes

• Front

  Ventilated disc 1-cylinder

• Rear

  Solid disc 1-cylinder

Weights & towing capacity

• Kerb Weight (kg)

  1190-1255 kg

• Gross vehicle weight (kg)

  1690 kg

Exterior dimensions

• Exterior length (mm)

  4172 mm

• Number Of Doors

  5

• Exterior height (mm)

  1595 mm

• Exterior width (mm)

  1765 mm

• Wheelbase (mm)

  2560 mm

• Front Tread (mm)

  1530 mm

• Rear Tread (mm)

  1529 mm

Interior dimensions

• Number Of Seats

  5 seats

Load Volume

• Luggage Capacity (litres)

  350 litres

Steering

• Minimum Turning Radius - Tyre (m)

  5.3

• Minimum Turning Radius (m)

  5.3 m

Multimedia

• Bluetooth® hands-free system

• Digital Audio Broadcast (DAB)

• 6 speakers

• 9" multimedia display

• MyT Connected Services

• Wireless Smartphone Integration

• Front USB Type-C connector

• Front USB Type-C device charger

• Toyota Touch® 3 multimedia system

Styling

• Soft-touch texture on lower dashboard

• 3-spoke leather steering wheel

• Silver insert on steering wheel

• Piano black side air vent surrounds

• Leather gear shift knob

• Satin chrome insert on gear shift knob

• Silver surround on gear shift console

• Electronic parking brake

• Fabric front door trim

• Grey roof lining

• Chrome surround on air conditioning buttons

• Silver insert on front interior door handles

Comfort

• Push-button start

• Digital tachometer

• Electric Power Steering (EPS)

• Manual day/night rear-view mirror

• Rear-view camera display in audio screen

• Static guide lines on rear-view camera display

• Automatic air conditioning

• Remote air conditioning system

• Pollen air filter

• Central armrest

• Height-adjustable driver seat

• Height-adjustable front passenger seat

• 60:40 split-folding rear seats

• Front power windows

• Rear power windows

• Auto up & down function on all power windows

• Anti-jam protection on power windows

• Power passenger window lock

• Noise reduction layer on windshield

• Centre room lamp (LED type)

• Boot lamp

• Mirror on driver sun visor

• Mirror on passenger sun visor

• Front 12V power outlet

• Power door lock

• Child safety door lock

• Key reminder warning

• Coloured TFT information displays

• 7" screen for information display

• Gear Shift Indicator (GSI)

• Audio switches on steering wheel

• Information display switches on steering wheel

• Telephone switch on steering wheel

• Voice recognition switch on steering wheel

• Adaptive Cruise Control switch on steering wheel

• Lane Departure Alert switch on steering wheel

• Speed Limiter switch on steering wheel

• Adjustable Speed Limiter (ASL) switch on steering wheel

• Automatic High Beam (AHB) on/off switch

• Front overhead assist grips

• Rear overhead assist grips

• Engine noise insulation cover

• Speed Limiter Information

• Intermittent rear wiper

• Digital speedometer (km/h)

• Manual tilting steering wheel

• Manual telescopic steering wheel

Transport

• Centre console box

• Lid on centre console box

• Single compartment glovebox

• Slow-opening on glovebox

• Front door pockets

• Rear door pockets

• Rear passenger coat hooks (2)

• Soft tonneau cover

• Boot underfloor storage

• Mono deckboard

• Front cup holders (2)

Protection

• Driver & front passenger fabric floor mats

• Embroidered Yaris Cross logo on floor mats

• Rear passenger fabric floor mats

Safety

• ISOFIX seat fixing

• Rear seat belt reminder

• Front passenger airbag on/off-switch

• Front seat belt reminder

• Driver & front passenger Whiplash Injury Lessening (WIL) seats

• Rear headrests (3)

• Adjustable rear headrests

• Driver & passenger front airbag

• Driver & passenger side airbag

• Driver & passenger central airbag

• Rear passenger side airbag

Wheels

• Temporary spare wheel

Styling

• Body-coloured front bumper

• Body-coloured rear bumper

• Body-coloured door handles

• Black wheel arch moulding

• Shark-fin antenna

• Black lower front grille

• Piano black insert on boot door

• Yaris Cross name plate insert on lower side doors

• Roof-coloured door mirrors

• Black upper front grille

Comfort

• Follow-me-home headlights

• Dusk sensor

• Automatic headlight cut-off

• Headlight cut-off reminder

• Rain sensor

• Standard opening of boot or tailgate

• Power-adjustable door mirrors

• Heated door mirrors

• Smart Entry & Start System

• Remote door lock

• Manually retractable door mirrors

Transport

• Pre-wiring for towing hook

Protection

• Black protection moulding on side doors

Performance

• Drive Mode Selector

• Rear spoiler

Safety

• Automatic High Beam (AHB)

• Turning signal integrated in door mirrors

• Daytime running lights (LED type)

• Projector halogen headlamps

• Front fog lamps (LED type)

• Brake Assist (BA)

• Rear-view camera

• Speed limiter

• Anti-lock Braking System (ABS) with Electronic Brake force Distribution (EBD)

• Emergency Brake-light Signal (EBS)

• Road Sign Assist (RSA)

• Hill-start Assist Control (HAC)

• Tyre Pressure Warning System (TPWS)

• Immobiliser

• High-mounted stop lamp (LED type)

• Traction Control (TRC)

• eCall emergency call system

• Driver Attention Alert

• Rear disc

• Turning signal (bulb type)

• Full-range Adaptive Cruise Control

• Lane Trace Assist (LTA)

• Pre-Collision System with Pedestrian and Cyclist Detection

• Emergency Steering Assist on Pre-Collision system

• Intelligent Adaptive Cruise Control (iACC)

• Steering-assisted Vehicle Stability Control (S-VSC)

• Rear combination lamps (LED & bulb)

• Intersection Turn Assist on Pre-Collision system

• Emergency Driving Stop System (EDSS)

• Acceleration suppression at low speed on Pre-Collision system (day)

• CO2 Low (g/km)

  73 g/km

• CO2 High (g/km)

  89 g/km

• CO2 Extra High (g/km)

  139 g/km

• Fuel Low (l/100 km)

  3.2 litres/100 km

• Fuel Medium (l/100 km)

  3.4 litres/100 km

• Fuel High (l/100 km)

  3.9 litres/100 km

• Fuel Extra High (l/100 km)

  6.1 litres/100 km

• Fuel Tank Capacity (l)

  36 l
